Asfaload Documentation

Welcome to the Asfaload documentation. Asfaload is a multi-signature sign-off solution that is:

open source
auditable as it is using a public git repo as storage
self-hostable
accountless, the keypair is the identity

Asfaload provides tools for signing and verifying software release artifacts. The Client CLI documentation explains how to use our command line utility to interact with the backend. The REST API details the endpoints of the backend server.

Sections

Concepts

Foundational terminology used throughout the Asfaload documentation: individual and aggregate signatures, the multisig system, the signers file, and the role-based signer groups.

Client CLI — How-to Guides

Step-by-step recipes for common operations: generating keys, creating signers files, registering releases, signing, and verification.

Client CLI — Manual

Reference for all client commands: options, environment variables, output formats, and exit codes.

REST API — Manual

Reference for the Asfaload REST API: endpoints, request/response formats, and error codes.

Asfaload Concepts

This document introduces concepts and terminology as used by the Asfaload project.

Individual signature

The signature generated by a user controlling an Asfaload keypair.

Multisig system

A system defining the combination of individual signatures from pre-defined groups of signers, each group specifying a threshold of participants as a completeness criterion.

Aggregate signature

A group of individual signatures in the Asfaload Multisig system. An aggregate signature is pending until its completeness criteria is met, at which time it transition to complete. This completeness criteria is dependent on the group and the operation the aggregate signature is applied to.

Signers file

The signers file is a json document that defines multiple role-based groups of signers, such as artifact_signers, admin_keys, revocation_keys, master_keys. Only the artifact_signers group is mandatory: to enable easy setup in simple environments, there are groups fallbacks if not all of these are defined. Each group has a specific purpose: artifact_signers applies to normal operations (e.g. release signing), while others apply to specific operations.

Groups

Artifact signers

Lists the public keys of the signers authorised and expected to sign an artifact, for example a Github Release. This group is mandatory.

Admin keys

Lists the public keys of signers authorised to update the signers file. Falls back to artifact_signers if absent or empty.

Revocation keys

Lists public keys of signers authorised to revoke an aggregate signature. The aggregate signature can be pending, in which case it cannot be completed anymore, or complete, in which case it is rendered obsolete. Falls back to admin keys if absent.

Master keys

These keys cannot be present in another group, and they are meant to be used in emergency operations when admin keys are not usable. We encourage keeping these keys offline. Optional, but does not fall back to another group if absent.

Trust anchor

When verifying signatures, you need to have an anchor of trust that enables to say: because the persons publishing the signers file have done it at that location, I trust the fact that they control that location. It is similar to Let’s Encrypt trusting the fact that you publishing information on your domain’s website or DNS entry show you are controlling that domain. With Asfaload we have a similar trust anchor: we trust that when you publish a signers file in your Github repository (or any other publishing platform supported), it shows you control that repository. This is because only a person controlling the repository can create a branch and publish a file there.

How-to guides

Step-by-step recipes for common operations with the asfaload-cli CLI. Follow them in order for a first-time setup, or jump to the one you need.

Project registration

Register a repository
Activate a signers file

Releases

Register a release
Sign a release

Maintenance

Update a signers file
Revoke a signed release

Verification

Download a file with signature verification

Generate a key pair

Every signer needs their own key pair. This guide walks you through creating one.

Prerequisites

The asfaload-cli binary is installed and in your PATH.

Steps

1. Choose a directory

By default the keys are generated in the current directory. A common convention, used throughout this guide, is to keep them together in ~/.asfaload/:

mkdir -p ~/.asfaload

2. Generate the key pair

asfaload-cli new-keys --name mykey --output-dir ~/.asfaload

Omit --output-dir to create the keys in the current directory instead.

You’ll be prompted for a password to protect the secret key. Pick a strong one — this password is required every time you sign.

This creates two files:

File	Purpose
`~/.asfaload/mykey`	Secret key (keep this safe)
`~/.asfaload/mykey.pub`	Public key (share with your team)

Demo: generate a key pair

3. Verify the output

ls ~/.asfaload/mykey*

You should see both mykey and mykey.pub.

Non-interactive usage

For CI or scripting, pass the password directly:

asfaload-cli new-keys --name ci-key --output-dir ./keys --password "$KEY_PASSWORD"

Or read the password from a file with --password-file (-P):

asfaload-cli new-keys --name ci-key --output-dir ./keys --password-file /run/secrets/key-password

The file should contain the password on a single line. Trailing newlines are stripped.

Or fetch the password from a password manager (or any external command) with --password-command (-c). The command’s standard output is used as the password:

asfaload-cli new-keys --name ci-key --output-dir ./keys \
    --password-command "pass show asfaload/ci-key"

The command string is parsed with shell-style quoting, but no shell is spawned — pipes and redirections don’t apply. Trailing newlines are stripped from the command’s output.

The password file and password command can also come from environment variables — ASFALOAD_PASSWORD_FILE and ASFALOAD_PASSWORD_COMMAND:

export ASFALOAD_PASSWORD_FILE="/run/secrets/key-password"
asfaload-cli new-keys --name ci-key --output-dir ./keys

The command-specific ASFALOAD_NEW_KEYS_PASSWORD and ASFALOAD_NEW_KEYS_PASSWORD_FILE are also still honoured (at lower precedence):

export ASFALOAD_NEW_KEYS_PASSWORD="$KEY_PASSWORD"
asfaload-cli new-keys --name ci-key --output-dir ./keys

Next step

Share your public key with whoever maintains the signers file. Use the share-key command to format it — see Share a public key. They’ll include it when creating the signers file.

Reference

asfaload-cli new-keys

Once you have a key pair, you need to share the public key with whoever maintains the signers file. The share-key command formats it for you.

Prerequisites

A public key file (.pub) from Generate a key pair.

Steps

asfaload-cli share-key -k ~/.asfaload/mykey.pub

This prints your public key together with a ready-to-send message you can forward to a team admin:

The public key is safe to share -- that's how others verify your signatures.

You can share your public key, for example with an admin, with this message:

    I have a key-pair to use with Asfaload. You can use my public
    key in signers files. Here it is:
    asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

2. Print only the key with `--raw`

When you only need the base64 string — for example, to paste it into a signers file — use --raw (-r):

asfaload-cli share-key -k ~/.asfaload/mykey.pub --raw

Output:

asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

This is the canonical base64 form used in signers files and templates.

--raw also works with OpenSSH ed25519 public keys — the key is normalised to its asfaload canonical form:

asfaload-cli share-key -k ~/.ssh/id_ed25519.pub --raw

--raw and --json are mutually exclusive; you cannot use both at the same time.

3. Machine-readable JSON output

For scripting, use --json:

asfaload-cli share-key -k ~/.asfaload/mykey.pub --json

Output:

{"public_key":"asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8","message":"The public key is safe to share -- ..."}

Next step

The admin will include your public key when creating the signers file.

Reference

asfaload-cli share-key

Create a signers file

A signers file defines who can sign artifacts for your project, and how many signatures are needed (the threshold). You create it once, commit it to your repository, then register it with the backend.

Prerequisites

Public key files (.pub) for every signer. See Generate a key pair.
A target repository where the signers file will live.

Steps

1. Collect the public keys

Gather .pub files from all signers. For this example, three artifact signers with a threshold of 2 (any two out of three must sign):

alice.pub
bob.pub
carol.pub

2. Create the signers file

asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    --artifact-signers-file carol.pub \
    --artifact-threshold 2 \
    --output-file signers.json

The command prints a summary, ending with the SHA-512 digest of the created file and its bishop art (a visual fingerprint of the digest — handy to spot-check the file later with get-digest):

Signers file created successfully at: signers.json
Artifact signers: 3 (threshold: 2)
Admin keys: 0 (threshold: none)
Master keys: 0 (threshold: none)
Revocation keys: 0 (threshold: none)
Generated file's digest: sha512:2e2fde4e...
+----[SHA-512]----+
|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|
| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|
|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|
|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|
| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|
|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|
|   ▁▎▏▁▎▂▎▏▏▏    |
|   ▁▁▁▏▄▃▍▎▏     |
|    ▁▁▎▍▅▋▍▏     |
+---[2e2fde4e…]---+

Demo: create the signers file

3. Commit and push

Place the signers file in your repository and push it. We advise to commit the file in your main branch (eg under a directory .asfaload.signers) or in a dedicated branch of the repo. You can choose any naming convention that suits you, as long as the file stays available at the URL, so that downloaders can confirm its validity. You could choose to place it in your main branch:

https://github.com/acme/tool/blob/main/asfaload.signers/index.json

or in a dedicated branch (in this example signers):

https://github.com/acme/tool/blob/signers/20260413_signers.json

If you publish an updated signers file, you must make it available at distinct URL. In other words, you must add a new file to your repo, and you must not edit an existing signers file.

The backend needs to fetch it by URL during repository registration.

A common location is at the root of your repo:

cp signers.json my-project/asfaload.signers/index.json
cd my-project
git add asfaload.signers/index.json
git commit -m "Add asfaload signers file"
git push

Adding optional key groups

Beyond artifact signers, you can define admin, master, and revocation key groups. Each group has its own keys and threshold.

With revocation keys

Revocation keys can revoke signed releases. Useful to have a separate set of keys for emergency access:

asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    --artifact-signers-file carol.pub \
    --artifact-threshold 2 \
    --revocation-keys-file revoke1.pub \
    --revocation-keys-file revoke2.pub \
    --revocation-keys-file revoke3.pub \
    --revocation-threshold 2 \
    --output-file signers.json

With admin keys

Admin keys can propose signers file updates:

asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    --artifact-threshold 2 \
    --admin-keys-file admin.pub \
    --admin-threshold 1 \
    --output-file signers.json

Mixing base64 strings and files

You can pass public keys as base64 strings instead of files. This is handy when keys come from a secrets manager:

asfaload-cli new-signers-file \
    --artifact-signer "asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8" \
    --artifact-signers-file bob.pub \
    --artifact-threshold 1 \
    --output-file signers.json

To obtain the base64 string from a .pub file, use share-key --raw:

asfaload-cli share-key -k alice.pub --raw

See Share a public key for more details.

Passing keys from a single file

For a longer signer list, repeating --artifact-signers-file quickly gets verbose. Each *-keys-file option reads one key per line, so you can collect several keys in a single text file and pass it once:

# signers.txt  (one base64 public key per line)
asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8
asfaload-pub:9wX6TbqMn2pPJ5vLV4R5gazKc2sQ7rH8oY3tV1uWfQk
asfaload-pub:7yQ4Tm1VxLpHoC2dRsKuVwMqY3nJbZ8iPtXaVeF9fBg

asfaload-cli new-signers-file \
    --af signers.txt \
    -A 2 \
    -o signers.json

The short alias --af (= --artifact-signers-file) keeps the command readable. The same --df, --mf, and --rf aliases exist for admin, master, and revocation key files.

Next step

Reference

asfaload-cli new-signers-file

Register a repository

Registering a repository tells the backend where your signers file lives. Once registered, the backend can enforce signature requirements for your project.

Prerequisites

A signers file committed and pushed to your repository. See Create a signers file.
Your secret key file. See Generate a key pair.
The backend is running and reachable.

Steps

1. Get the signers file URL

You need the public URL that points to your signers file on the forge. For GitHub, you can simply copy the URL from your browser when displaying the file of your repo. This will give you an URL of this form:

https://github.com/acme/tool/blob/main/asfaload.signers/index.json

2. Register the repository

asfaload-cli register-repo \
    --secret-key ~/.asfaload/mykey \
    https://github.com/acme/tool/blob/main/asfaload.signers/index.json

On success:

Repository registered successfully!
Project ID: abc123
Required signers (3): alice, bob, carol
Next step: signers must submit signatures to activate the project.

The backend fetches the signers file, creates a pending signers entry, and waits for all listed signers to sign before the project becomes active.

Demo: register a repository

3. Point to a non-default backend

If your backend is not Asfaload’s:

asfaload-cli register-repo \
    --secret-key ~/.asfaload/mykey \
    -u https://my-asfaload-deployment.example.com \
    https://github.com/acme/tool/blob/main/asfaload.signers/index.json

What happens next

After registration, the signers file is in a pending state. Every signer listed in it must sign before the project is activated. See Activate a signers file.

Reference

asfaload-cli register-repo

Activate a signers file

After a repository is registered (or a signers file is updated), the signers file sits in a pending state. Every signer listed in it must sign before the project becomes active. This guide covers the signing round.

Prerequisites

A repository has been registered or a signers file update proposed.
Each signer has their own secret key. See Generate a key pair.

Steps

Each signer performs steps 1–2 independently.

1. Check for pending work

asfaload-cli list-pending --secret-key ~/.asfaload/mykey

If the signers file is waiting for your signature, you’ll see its path, its digest, and a bishop art block (a small picture derived from the digest, acting as a visual fingerprint):

Files requiring your signature:
  - path: https/github.com/443/acme/tool/asfaload.signers.pending/index.json
digest: sha512:2e2fde4ead7c6846656431dd4f2d2f3013e2b35d31fc32978fc03a32f54034589d65ab6666a72aab3835bf409dc7b86fdab6b2f488486c4012c0acffc41438d7

+----[SHA-512]----+
|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|
| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|
|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|
|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|
| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|
|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|
|   ▁▎▏▁▎▂▎▏▏▏    |
|   ▁▁▁▏▄▃▍▎▏     |
|    ▁▁▎▍▅▋▍▏     |
+---[2e2fde4e…]---+

If nothing is pending for you, the output says No pending signatures found.

2. Sign the pending signers file

Copy the path and the digest from the output above and pass both to sign-pending:

asfaload-cli sign-pending --secret-key ~/.asfaload/mykey \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/tool/asfaload.signers.pending/index.json

If more signatures are needed:

Success! Your signature has been included, but the aggregate signature is not yet complete. Other signers must still provide their signatures.

When your signature completes the required count (every signer must sign for an initial signers file):

Success! Your signature has been included and the aggregate signature is now complete. No further signature will be included in this aggregate signature.

Demo: sign the pending signers file

3. Verify activation

Once every signer has signed, the signers file moves from pending to active. There is no separate activation step — the last signature triggers it automatically.

Coordinating signers

Signers don’t need to sign in any particular order. The workflow looks like:

alice: asfaload-cli list-pending --secret-key alice.key    → sees pending signers
alice: asfaload-cli sign-pending --secret-key alice.key ...  → "not yet complete"

bob:   asfaload-cli list-pending --secret-key bob.key      → sees pending signers
bob:   asfaload-cli sign-pending --secret-key bob.key ...    → "not yet complete"

carol: asfaload-cli list-pending --secret-key carol.key    → sees pending signers
carol: asfaload-cli sign-pending --secret-key carol.key ...  → "now complete"

Scripting the sign step

For CI, supply the password and digest non-interactively:

asfaload-cli sign-pending \
    --secret-key ~/.asfaload/mykey \
    --password-file "/path/to/password-file" \
    --digest "sha512:2e2fde4e..." \
    https/github.com/443/acme/tool/asfaload.signers.pending/index.json

If several files are pending, --digest-filter (alias --df) restricts both list-pending output and the interactive selection of sign-pending to a single digest:

asfaload-cli list-pending --secret-key ~/.asfaload/mykey --df sha512:2e2fde4e...

On an interactive terminal you can also omit the path and digest entirely: sign-pending then shows a selection prompt listing each pending file with its bishop art.

Troubleshooting

“Already completed” error when signing — someone else already provided the final signature. The signers file is active; no action needed.

list-pending returns empty — either your key is not listed in the signers file, or the file has already been fully signed.

Next step

Once the signers file is active, you can register a release for signing.

Reference

asfaload-cli list-pending
asfaload-cli sign-pending

Register a release

Once your project’s signers file is active, you can register releases for signing. The backend will index the release assets and start a signature collection round.

Prerequisites

The repository is registered and the signers file is activated.
The release is published on the forge (e.g., a GitHub release page exists).
Your secret key file. See Generate a key pair.

Register a GitHub release

Pass the release page URL:

asfaload-cli register-assets \
    --secret-key ~/.asfaload/mykey \
    --github-release-url https://github.com/acme/tool/releases/tag/v1.0

On success:

Assets registered successfully! Remember you still need to sign it yourself!
Index file path: https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

The backend fetches the release, creates an index of the assets, and waits for signatures.

Demo: register a release

Register a release from other hoster [EXPERIMENTAL]

Github is currently the only forge publishing digests of the releases’ artifacts. If you publish releases on other forges or an http file server, your release needs to publish a checksums file (using sha256sum or sha512sum). It is that checksums file that you will register with Asfaload.

asfaload-cli register-assets \
    --secret-key ~/.asfaload/mykey \
    --csum-file https://example.com/releases/v1.0/SHA256SUMS \
    --csum-file https://example.com/releases/v1.0/SHA512SUMS

All checksum file URLs must share a common parent path. --csum-file is repeatable; --github-release-url and --csum-file are mutually exclusive.

Re-registration

Registering the same release twice fails — the backend rejects duplicates. Existing signatures are preserved; there’s no risk of losing progress.

What happens next

You registered the release, but you haven’t signed it yet. The backend is now waiting for enough signatures to meet the threshold. See Sign a release.

Reference

asfaload-cli register-assets

Sign a release

After a release is registered, artifact signers must provide enough signatures to meet the threshold defined in the signers file. This is the same list-pending / sign-pending flow used for activating a signers file, but applied to a release index.

Prerequisites

A release has been registered.
Your key is listed as an artifact signer in the active signers file.

Steps

1. List pending files

asfaload-cli list-pending --secret-key ~/.asfaload/mykey

Each pending file is listed with its path, its digest, and a bishop art block derived from the digest:

Files requiring your signature:
  - path: https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json
digest: sha512:2e2fde4ead7c6846656431dd4f2d2f3013e2b35d31fc32978fc03a32f54034589d65ab6666a72aab3835bf409dc7b86fdab6b2f488486c4012c0acffc41438d7

+----[SHA-512]----+
|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|
| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|
|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|
|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|
| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|
|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|
|   ▁▎▏▁▎▂▎▏▏▏    |
|   ▁▁▁▏▄▃▍▎▏     |
|    ▁▁▎▍▅▋▍▏     |
+---[2e2fde4e…]---+

2. Sign the release index

Copy the path and the digest from the output above:

asfaload-cli sign-pending --secret-key ~/.asfaload/mykey \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

The command fetches all files associated with the release, hashes each one, signs the hashes, and submits everything in a single request.

If more signatures are needed:

Success! Your signature has been included, but the aggregate signature is not yet complete. Other signers must still provide their signatures.

When the threshold is met:

Success! Your signature has been included and the aggregate signature is now complete. No further signature will be included in this aggregate signature.

Demo: sign a release

3. Check progress

At any point, you can check whether the threshold has been reached:

asfaload-cli signature-status --secret-key ~/.asfaload/mykey \
    https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json: pending

https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json: complete

Example: two-of-three threshold

With three artifact signers and a threshold of 2, only two need to sign:

alice: asfaload-cli sign-pending --secret-key alice.key ...  → "not yet complete"
bob:   asfaload-cli sign-pending --secret-key bob.key ...    → "now complete"
# carol doesn't need to sign — threshold already met

Next step

Once the release is fully signed, users can download it with verification.

Reference

asfaload-cli list-pending
asfaload-cli sign-pending
asfaload-cli signature-status

Update a signers file

Need to add a signer, remove one, or change the threshold? This guide covers proposing and activating a signers file update.

Prerequisites

The repository is already registered and the current signers file is active.
A new signers file has been created (see Create a signers file), committed, and pushed to the forge.
Your secret key file. See Generate a key pair.

Steps

1. Create and push the new signers file

Generate a new signers file with the updated set of keys and thresholds:

asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    --artifact-signers-file carol.pub \
    --artifact-signers-file dave.pub \
    --artifact-threshold 3 \
    --revocation-keys-file revoke1.pub \
    --revocation-keys-file revoke2.pub \
    --revocation-keys-file revoke3.pub \
    --revocation-threshold 2 \
    --output-file signers_v2.json

Commit and push it to your repository so the backend can fetch it by URL. We advise to commit the file either in your main branch, or in a dedicated branch in which you save all signers files updates.

2. Propose the update

asfaload-cli update-signers \
    --secret-key ~/.asfaload/mykey \
    https://github.com/acme/tool/blob/main/asfaload.signers/index.json

On success:

Signers update proposed successfully!
Project ID: abc123
Required signers (4): alice, bob, carol, dave
Next step: signers must submit signatures to activate the update.

Demo: propose a signers update

3. All signers must sign

Just like initial activation, every signer listed in the new signers file must sign before the update takes effect. This includes both existing and newly added signers.

Each signer runs:

asfaload-cli list-pending --secret-key ~/.asfaload/mykey
asfaload-cli sign-pending --secret-key ~/.asfaload/mykey \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/tool/asfaload.signers.pending/index.json

The digest is taken from the list-pending output. See Activate a signers file for the full signing flow.

What about existing releases?

Releases signed under the previous signers file remain valid. The backend keeps a signers chain history, so older releases can still be verified against the signers file that was active when they were signed.

Reference

asfaload-cli new-signers-file
asfaload-cli update-signers

Revoke a signed release

If a release needs to be recalled — a vulnerability was found, or the wrong artifacts were published — you can revoke it. Revoked files can no longer be downloaded with verification.

Prerequisites

The release is fully signed and active on the backend.
Your key is listed as a revocation key in the active signers file. Artifact signers without revocation privileges cannot revoke.
The signers file has a revocation group with a threshold. See Create a signers file.

Steps

1. Initiate the revocation

asfaload-cli revoke \
    --secret-key ~/.asfaload/revoke-key \
    https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

On success:

Success! File revoked: https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

If the revocation threshold is 1, the file is revoked immediately. If the threshold is higher, the revocation enters a pending state and more revocation signers must co-sign.

Demo: initiate a revocation

2. Co-sign the revocation (if threshold > 1)

When the revocation threshold requires multiple signatures, additional revocation signers use list-pending and sign-pending to add their signatures:

# Another revocation signer checks for pending work
asfaload-cli list-pending --secret-key ~/.asfaload/revoke-key-2

The pending revocation shows up as a path ending in .revocation.json.pending, together with its digest and bishop art:

Files requiring your signature:
  - path: https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json.revocation.json.pending
digest: sha512:2e2fde4e...

Sign it (copy path and digest from the output above):

asfaload-cli sign-pending --secret-key ~/.asfaload/revoke-key-2 \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json.revocation.json.pending

Once the threshold is met, the revocation is finalized.

Demo: co-sign a revocation

3. Verify the revocation

Attempting to download a revoked file fails:

asfaload-cli download https://github.com/acme/tool/releases/download/v1.0/artifact.bin

This file has been revoked.
  Revoked at: 2025-03-15T10:30:00Z
  Revoked by: asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

Important notes

Only revocation keys can revoke. Artifact signers listed in the artifact_signers group cannot initiate or co-sign a revocation.
Revocation is irreversible. Once a file is revoked, it stays revoked.
Other releases are unaffected. Revoking v1.0 does not impact v2.0.
Re-initiating a pending revocation fails. If a revocation is already pending, starting another one for the same file is rejected.

Reference

asfaload-cli revoke
asfaload-cli list-pending
asfaload-cli sign-pending

Download a file with signature verification

The download command fetches a file and verifies its signatures before saving it to disk. If the signatures don’t check out, or the file has been revoked, the download is aborted.

Prerequisites

The file has been signed on the backend (signatures meet the threshold).
The backend is running and reachable.

Steps

1. Download a release artifact

Pass the original download URL — the same URL you’d use to download from GitHub or your forge:

asfaload-cli download \
    https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

The command prints each verification step:

Starting download: https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz
✓ Downloaded index file (567 bytes)
✓ Downloaded signatures file (890 bytes)
Downloading tool-linux-amd64.tar.gz
Progress: 2.00 MB
✓ Signers chain history verified (3 entries)
✓ Signatures verified successfully (2 valid)
✓ Download complete (12.50 MB)
✓ File hash verified (SHA-256)
✓ File saved to: ./tool-linux-amd64.tar.gz
✓ All done! Verified 2 signature(s)

The file download, signers chain validation, and revocation probe run in parallel, so the Progress: and ✓ Signers chain history verified lines may interleave in any order.

Demo: download with verification

2. Choose where to save

By default, the file is saved in the current directory using the filename from the URL. Use -o to specify a different path:

asfaload-cli download -o /tmp/tool.tar.gz \
    https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

Signers chain verification

The full signers chain history is always verified as part of the download — there is no flag to skip it. The chain is walked entry by entry and each entry is verified against the forge, catching tampering in historical signers files (e.g. a signers file updated since the release was signed). A successful check prints:

✓ Signers chain history verified (3 entries)

If chain validation fails, a ✗ Signers chain verification failed: <reason> line is printed to stderr and the download is aborted.

Overriding forge detection

The CLI auto-detects the forge type from the URL. If detection fails or you’re using a generic file server:

asfaload-cli download --type fileserver \
    https://files.example.com/tool/v1.0/tool.tar.gz

Available types: github, gitlab, fileserver.

Pointing to a non-default backend

asfaload-cli download -u https://asfaload.example.com \
    https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

What happens with revoked files

If the file has been revoked, the download fails:

This file has been revoked.
  Revoked at: 2025-03-15T10:30:00Z
  Revoked by: asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

Reference

asfaload-cli download

asfaload-cli manual

Reference for all asfaload-cli commands.

Keys

new-keys — generate a new signing key pair
share-key — print your public key and a message for sharing it

Signers

new-signers-file — create a signers file defining authorized keys and thresholds
update-signers — propose an update to an existing signers file

Registration

register-repo — register a repository with the backend
register-assets — register assets (GitHub release or checksum files) for signing

Signing

list-pending — list files that still need your signature
sign-pending — sign a pending file
signature-status — check a file’s signature collection status

Revocation

revoke — revoke a previously signed file

Verification

get-digest — compute the SHA-512 digest of a local file or URL
download — download a file with signature verification

Diagnostics

ping — check backend connectivity and, optionally, your credentials

Common notes

Passwords

Password sources are tried in this order: --password, then --password-command (flag or ASFALOAD_PASSWORD_COMMAND), then --password-file (flag or ASFALOAD_PASSWORD_FILE), then the command-specific variables (ASFALOAD_<COMMAND>_PASSWORD, ASFALOAD_<COMMAND>_PASSWORD_FILE), then an interactive prompt.

JSON errors

When --json is active and a command fails, the error is printed to stderr as {"error":"<message>"} and the process exits non-zero.

`asfaload-cli new-keys`

Usage: asfaload-cli new-keys [OPTIONS] -n <NAME>
Source: src/commands/keys.rs

Generate a new signing key pair. The command creates both a secret key and a public key in the specified directory.

Options

`-n --name <NAME>`

Base name for the key files. Produces <NAME> (secret key) and <NAME>.pub (public key) in the output directory.

`-d --output-dir <DIR>`

Directory to write the key files into. Defaults to the current directory; ~/.asfaload is a common place to keep keys. Created automatically if it doesn’t exist.

`-p --password <PASSWORD>`

Password to protect the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

Shell command to run; its standard output is read as the password. Useful for password managers (pass, op, bw, etc.). Conflicts with --password and --password-file. The command string is parsed with shell-style quoting (no shell is spawned, so pipes and redirections don’t apply); trailing newlines are stripped from the output.

`--accept-weak-password`

Bypass password strength validation. Insecure — only use for testing.

`--json`

Emit output as JSON instead of human-readable text.

Environment

These variables provide fallbacks for the matching options. Password sources are tried in the order described in the manual index: flags first (in the order --password, --password-command, --password-file), then environment variables, then an interactive prompt.

ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_NEW_KEYS_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_NEW_KEYS_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

Generated keypair 'mykey'

  Public key string:  asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8
  Public key file: /home/user/.asfaload/mykey.pub
  Secret key file: /home/user/.asfaload/mykey

WARNING: Keep the secret key private. Treat it like a password -- never share, copy, or commit it.
The public key is safe to share -- that's how others verify your signatures.

You can share your public key, for example with an admin, with this message:

    I have a key-pair to use with Asfaload. You can use my public
    key in signers files. Here it is:
    asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

The trailing message is the same text printed by share-key; it can be copy-pasted directly when sharing the key.

JSON (with --json):

{"public_key_path":"/home/user/.asfaload/mykey.pub","public_key":"asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8","secret_key_path":"/home/user/.asfaload/mykey"}

Examples

# generate a key pair in the current directory
asfaload-cli new-keys -n mykey

# store keys in the usual location
asfaload-cli new-keys -n mykey -d ~/.asfaload

# non-interactive usage in CI
asfaload-cli new-keys -n ci-key -d ./keys -p "$KEY_PASSWORD"

Exit codes

0 — key pair created successfully.
non-zero — error (invalid directory, password mismatch, etc.).

Usage: asfaload-cli share-key [OPTIONS] -k <PUBLIC_KEY>
Source: src/commands/share_key.rs

Print your public key in the base64 form used in signers files, along with a ready-to-send message for sharing it. The public key is safe to share — it is how others verify your signatures.

This command is offline: it only reads a local public key file and never contacts the backend.

Options

`-k --public-key <PATH>`

Path to the public key file to share (asfaload or OpenSSH ed25519). Required. If the path does not contain a parseable public key, the command retries with .pub appended to the path — so passing the secret key path also works, as long as its .pub sibling exists.

`-r --raw`

Print only the public key in its canonical base64 form (asfaload-pub:...), without the human-readable message. Conflicts with --json.

`--json`

Emit output as JSON instead of human-readable text. Conflicts with --raw.

Output

Human-readable (default):

The public key is safe to share -- that's how others verify your signatures.

You can share your public key, for example with an admin, with this message:

    I have a key-pair to use with Asfaload. You can use my public
    key in signers files. Here it is:
    asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

Raw (with --raw):

asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

JSON (with --json):

{"public_key":"asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8","message":"The public key is safe to share -- ..."}

Examples

# print your public key and a sharing message
asfaload-cli share-key -k ~/.asfaload/mykey.pub

# print only the key
asfaload-cli share-key -k ~/.asfaload/mykey.pub --raw

# machine-readable output
asfaload-cli share-key --json -k ~/.asfaload/mykey.pub

Exit codes

0 — public key loaded and printed.
non-zero — error (public key file missing or unreadable, invalid key).

`asfaload-cli new-signers-file`

Usage: asfaload-cli new-signers-file [OPTIONS] --artifact-threshold <ARTIFACT_THRESHOLD>
Source: src/commands/signers_file.rs

Create a new signers file that defines who can sign artifacts, administer, and manage the project. At minimum, one artifact signer and its threshold are required.

Options

Artifact signers

Every signers file needs at least one artifact signer.

`-a --artifact-signer <PUB_KEY>`

Public key as a base64 string. Repeatable.

`--artifact-signers-file <FILE_PATH>` (`--af`)

Path to a file holding public keys, one per line. Repeatable. Combines with --artifact-signer.

`-A --artifact-threshold <N>`

Number of artifact signers required to complete a signature. Must be between 1 and the total number of artifact signers.

Admin keys (optional)

`-d --admin-key <PUB_KEY>`

Admin public key as a base64 string. Repeatable.

`--admin-keys-file <FILE_PATH>` (`--df`)

Path to a file holding admin public keys, one per line. Repeatable. Combines with --admin-key.

`-D --admin-threshold <N>`

Required when admin keys are provided. Number of admins required to approve changes.

Master keys (optional)

`-m --master-key <PUB_KEY>`

Master public key as a base64 string. Repeatable.

`--master-keys-file <FILE_PATH>` (`--mf`)

Path to a file holding master public keys, one per line. Repeatable. Combines with --master-key.

`-M --master-threshold <N>`

Required when master keys are provided.

Revocation keys (optional)

`-r --revocation-key <PUB_KEY>`

Revocation public key as a base64 string. Repeatable.

`--revocation-keys-file <FILE_PATH>` (`--rf`)

Path to a file holding revocation public keys, one per line. Repeatable. Combines with --revocation-key.

`-R --revocation-threshold <N>`

Required when revocation keys are provided.

General

`-o --output-file <OUTPUT_FILE>`

Path for the new signers file. The file must not already exist — the command refuses to overwrite. Parent directories are created automatically. Required when --json is used; otherwise the signers file is printed to stdout if omitted.

`--json`

Emit output as JSON instead of human-readable text.

Output

Human-readable (default):

Signers file created successfully at: signers.json
Artifact signers: 3 (threshold: 2)
Admin keys: 1 (threshold: 1)
Master keys: 0 (threshold: none)
Revocation keys: 0 (threshold: none)
Generated file's digest: sha512:2e2fde4e...
+----[SHA-512]----+
|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|
| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|
|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|
|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|
| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|
|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|
|   ▁▎▏▁▎▂▎▏▏▏    |
|   ▁▁▁▏▄▃▍▎▏     |
|    ▁▁▎▍▅▋▍▏     |
+---[2e2fde4e…]---+

The trailing digest and bishop art are a fingerprint of the created file; see get-digest for how to recompute and compare it later.

JSON (with --json):

{"output_file":"signers.json","artifact_signers_count":3,"artifact_threshold":2,"admin_keys_count":1,"admin_threshold":1,"master_keys_count":0,"master_threshold":null,"revocation_keys_count":0,"revocation_threshold":null,"digest":"sha512:2e2fde4e...","bishop_art":"+----[SHA-512]----+\n|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|\n| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|\n|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|\n|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|\n| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|\n|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|\n|   ▁▎▏▁▎▂▎▏▏▏    |\n|   ▁▁▁▏▄▃▍▎▏     |\n|    ▁▁▎▍▅▋▍▏     |\n+---[2e2fde4e…]---+"}

Examples

# minimal: two artifact signers, threshold of 2
asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    -A 2 \
    -o signers.json

# with admin and revocation groups
asfaload-cli new-signers-file \
    --artifact-signers-file alice.pub \
    --artifact-signers-file bob.pub \
    -A 2 \
    --admin-keys-file admin.pub \
    -D 1 \
    --revocation-keys-file revoke.pub \
    -R 1 \
    -o signers.json

# mix base64 strings and files
asfaload-cli new-signers-file \
    -a "asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8" \
    --artifact-signers-file bob.pub \
    -A 1 \
    -o signers.json

# one key per line in a single file (--af is an alias for --artifact-signers-file)
asfaload-cli new-signers-file \
    --af signers.txt \
    -A 2 \
    -o signers.json

Exit codes

0 — signers file created.
non-zero — error (output file exists, invalid threshold, missing keys, etc.).

`asfaload-cli update-signers`

Usage: asfaload-cli update-signers [OPTIONS] -K <SECRET_KEY> <SIGNERS_FILE_URL>
Source: src/commands/update_signers.rs

Propose an update to an existing project’s signers file. The backend fetches the new file from the forge and starts a signature collection round — signers from the current configuration must approve the change before it takes effect.

Arguments

`<SIGNERS_FILE_URL>`

Public URL to the new signers file on the forge. For example:

https://raw.githubusercontent.com/owner/repo/main/asfaload.signers/index.json

Options

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit output as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_UPDATE_SIGNERS_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_UPDATE_SIGNERS_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

Signers update proposed successfully!
Project ID: abc123
Required signers (2): alice, bob
Next step: signers must submit signatures to activate the update.

JSON (with --json):

{"success":true,"project_id":"abc123","message":"","required_signers":["alice","bob"],"signature_submission_url":"/v1/signatures"}

Examples

# propose a signers update
asfaload-cli update-signers -K ~/.asfaload/key \
    https://raw.githubusercontent.com/acme/tool/main/asfaload.signers/index.json

Exit codes

0 — update proposed.
non-zero — error (authentication failure, invalid signers file, network error).

`asfaload-cli register-repo`

Usage: asfaload-cli register-repo [OPTIONS] -K <SECRET_KEY> <SIGNERS_FILE_URL>
Source: src/commands/register_repo.rs

Register a new repository with the backend. Points the backend at your signers file so it knows which keys are authorized to sign artifacts for this project.

After registration, all signers listed in the file must submit their signatures to activate the project.

Arguments

`<SIGNERS_FILE_URL>`

Public URL to the signers file on the forge. For example:

https://raw.githubusercontent.com/owner/repo/main/asfaload.signers/index.json

Options

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit output as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_REGISTER_REPO_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_REGISTER_REPO_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

Repository registered successfully!
Project ID: abc123
Required signers (2): alice, bob
Next step: signers must submit signatures to activate the project.

JSON (with --json):

{"success":true,"project_id":"abc123","message":"","required_signers":["alice","bob"],"signature_submission_url":"/v1/signatures"}

Examples

# register a GitHub-hosted signers file
asfaload-cli register-repo -K ~/.asfaload/key \
    https://raw.githubusercontent.com/acme/tool/main/asfaload.signers/index.json

# with explicit backend
asfaload-cli register-repo -K ~/.asfaload/key \
    -u https://asfaload.example.com \
    https://raw.githubusercontent.com/acme/tool/main/asfaload.signers/index.json

Exit codes

0 — repository registered.
non-zero — error (authentication failure, invalid signers file URL, network error).

`asfaload-cli register-assets`

Usage: asfaload-cli register-assets [OPTIONS] -K <SECRET_KEY>
Source: src/commands/register_assets.rs

Register assets for signing. Tell the backend about a new set of files — either a GitHub release or one or more checksum files — so that the signature collection process can begin.

After registration you still need to sign the assets yourself with sign-pending.

Options

`--github-release-url <URL>`

URL of a GitHub release page. The backend fetches the release assets automatically. The host must be a known GitHub host (e.g. github.com); anything else is rejected. Mutually exclusive with --csum-file.

`--csum-file <URL>`

URL of a checksums file. Repeatable — pass once per file. All URLs must share the same origin (scheme, host, and port) and a common parent path. Mutually exclusive with --github-release-url.

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit output as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_REGISTER_ASSETS_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_REGISTER_ASSETS_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

Assets registered successfully! Remember you still need to sign it yourself!
Index file path: https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json

JSON (with --json):

{"success":true,"message":"","index_file_path":"https/github.com/443/acme/tool/releases/tag/v1.0/asfaload.index.json"}

Examples

# register a GitHub release
asfaload-cli register-assets -K ~/.asfaload/key \
    --github-release-url https://github.com/acme/tool/releases/tag/v1.0

# register checksum files
asfaload-cli register-assets -K ~/.asfaload/key \
    --csum-file https://example.com/releases/v1.0/SHA256SUMS \
    --csum-file https://example.com/releases/v1.0/SHA512SUMS

Exit codes

0 — assets registered.
non-zero — error (authentication failure, invalid URL, mutually exclusive flags, network error).

`asfaload-cli list-pending`

Usage: asfaload-cli list-pending [OPTIONS] -K <SECRET_KEY>
Source: src/commands/list_pending.rs

List all files on the backend that still need your signature. The command authenticates with your secret key and returns only the files where your public key is among the expected signers.

Options

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--digest-filter <DIGEST>` (`--df`)

Only list pending files whose digest matches the given value. The value must be a full sha512:<128 hexadecimal characters> digest (e.g. as printed by get-digest or in the list output itself); anything else is rejected. Filtered results are subject to the same output rules as unfiltered ones (an empty result prints No pending signatures found.).

`--json`

Emit the backend response as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_LIST_PENDING_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_LIST_PENDING_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default), when files are pending. Each entry shows the path and its digest, followed by a “bishop art” block derived from the digest — a visual fingerprint you can compare at a glance (art shown here for the digest of the example file):

Files requiring your signature:
  - path: https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json
digest: sha512:2e2fde4ead7c6846656431dd4f2d2f3013e2b35d31fc32978fc03a32f54034589d65ab6666a72aab3835bf409dc7b86fdab6b2f488486c4012c0acffc41438d7

+----[SHA-512]----+
|▍  ▏ ▏   ▎▃▎▏▍▂ ▏|
| ▎▁ ▁ E ▏▏▎▎▃▏▎▎▁|
|▁ ▏▁ ▏   ▎▁▏ ▎▁▍▏|
|▏▁  ▏  ▏ ▎▂▎▁▁▎▏▂|
| ▏▏▁  ▏ S▎▎▎▃▏▏▍▏|
|  ▏▁▁▏▁▏▎▎▁▂▏▁▏ ▏|
|   ▁▎▏▁▎▂▎▏▏▏    |
|   ▁▁▁▏▄▃▍▎▏     |
|    ▁▁▎▍▅▋▍▏     |
+---[2e2fde4e…]---+

When nothing is pending:

No pending signatures found.

JSON (with --json):

{"pending_files":[{"path":"https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json","digest":"sha512:2e2fde4ead7c6846656431dd4f2d2f3013e2b35d31fc32978fc03a32f54034589d65ab6666a72aab3835bf409dc7b86fdab6b2f488486c4012c0acffc41438d7"}]}

An empty result serializes as {"pending_files":[]}.

Examples

# list pending files
asfaload-cli list-pending -K ~/.asfaload/key

# list pending files for one specific digest
asfaload-cli list-pending --df sha512:2e2fde4e... -K ~/.asfaload/key

# non-interactive, piped into sign-pending
asfaload-cli list-pending --json -K ~/.asfaload/key -p "$PASSWORD" \
    | jq -r '.pending_files[0] | "--digest \(.digest) \(.path)"' \
    | xargs asfaload-cli sign-pending -K ~/.asfaload/key -p "$PASSWORD"

Exit codes

0 — query succeeded (even if no files are pending).
non-zero — error (authentication failure, network error).

`asfaload-cli sign-pending`

Usage: asfaload-cli sign-pending [OPTIONS] -K <SECRET_KEY> [<FILE_PATH> --digest <DIGEST>]
Source: src/commands/sign_pending.rs

Sign a pending file. The command fetches all files associated with the given path from the backend, computes a SHA-512 hash of each, signs them with your secret key, and submits the signatures in a single request.

Use list-pending to discover which files need signing.

Arguments

`<FILE_PATH>`

Mirror-relative path to the file to sign, as returned by list-pending. For example https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json. Optional: if omitted, an interactive selector is shown (see below).

<FILE_PATH> and --digest are tied together: passing one requires the other.

Options

`--digest <DIGEST>`

The sha512:<128 hexadecimal characters> digest of the file to sign, as printed by list-pending or get-digest. Required when <FILE_PATH> is given. Before signing, the digest of the fetched file is verified against this value and the command aborts on mismatch.

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--digest-filter <DIGEST>` (`--df`)

Only used when <FILE_PATH> is omitted: pre-filters the interactive selection list to pending files matching the given sha512:<128 hexadecimal characters> digest. Same value format as --digest.

`--json`

Emit output as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_SIGN_PENDING_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_SIGN_PENDING_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Interactive selection

When <FILE_PATH> (and therefore --digest) is omitted, the command fetches your pending files and, on a terminal, shows an interactive Select prompt. Each proposal lists the file path, its digest, and its bishop art so you can visually confirm you are signing the intended file. Use --digest-filter to narrow the list beforehand.

If nothing is pending, the command fails with No pending signature found. If stdin is not a terminal (e.g. in CI), the command fails with Not a tty and no path to sign was passed. — pass <FILE_PATH> and --digest explicitly in that case.

Output

Human-readable (default), when the aggregate signature is now complete:

Success! Your signature has been included and the aggregate signature is now complete. No further signature will be included in this aggregate signature.

When other signers must still provide their signatures:

Success! Your signature has been included, but the aggregate signature is not yet complete. Other signers must still provide their signatures.

JSON (with --json):

{"is_complete":true}

Examples

# sign a pending release index
asfaload-cli sign-pending -K ~/.asfaload/key \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

# sign with explicit password (CI usage)
asfaload-cli sign-pending -K ~/.asfaload/key -p "$PASSWORD" \
    --digest sha512:2e2fde4e... \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

# interactive selection from the pending list
asfaload-cli sign-pending -K ~/.asfaload/key

# interactive selection, restricted to one digest
asfaload-cli sign-pending -K ~/.asfaload/key --df sha512:2e2fde4e...

Exit codes

0 — signature submitted successfully.
non-zero — error (authentication failure, file not found, network error).

`asfaload-cli signature-status`

Usage: asfaload-cli signature-status [OPTIONS] <FILE_PATH>
Source: src/commands/signature_status.rs
Related endpoint: GET /v1/signatures/{file_path}

Query the backend for the signature collection status of a file. The caller must be an authorized signer in the file’s current signers file; see the linked endpoint for the exact authorization rule.

Arguments

`<FILE_PATH>`

Mirror-relative path to the file to query, for example https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json.

Options

`-K --secret-key <PATH>`

Path to the caller’s secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit the backend response as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_SIGNATURE_STATUS_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_SIGNATURE_STATUS_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

<file_path>: pending

<file_path>: complete

JSON (with --json):

{"file_path":"<file_path>","is_complete":false}

Examples

# check a pending release index
asfaload-cli signature-status -K ~/.asfaload/key \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

# use a non-default backend
asfaload-cli signature-status -K ~/.asfaload/key -u https://asfaload.example.com \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

# machine-readable output
asfaload-cli signature-status --json -K ~/.asfaload/key \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

Exit codes

0 — query succeeded.
non-zero — error (authentication failure, not authorized, file not found, network error).

`asfaload-cli revoke`

Usage: asfaload-cli revoke [OPTIONS] -K <SECRET_KEY> <FILE_PATH>
Source: src/commands/revoke.rs

Revoke a previously signed file on the mirror. The command fetches the file from the backend, builds a revocation document (timestamped, with the initiator’s public key and the file’s SHA-512 digest), signs it, and submits it.

Once revoked, clients that download the file will see a revocation warning.

Arguments

`<FILE_PATH>`

Mirror-relative path to the signed file, for example https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json.

Options

`-K --secret-key <PATH>`

Path to your secret key file. Required.

`-p --password <PASSWORD>`

Password for the secret key. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit output as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_REVOKE_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_REVOKE_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default):

Success! File revoked: https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

JSON (with --json):

{"success":true,"message":""}

Examples

# revoke a release index
asfaload-cli revoke -K ~/.asfaload/key \
    https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json

Exit codes

0 — file revoked.
non-zero — error (authentication failure, file not found, not authorized, network error).

`asfaload-cli download`

Usage: asfaload-cli download [OPTIONS] <FILE_URL>
Source: src/commands/download.rs

Download a file and verify its signatures before saving. The command fetches the index and its signatures from the backend, validates the full signers chain history, probes for a revocation, and downloads the actual file. The download, chain validation and revocation probe run in parallel: a failed verification or a detected revocation aborts the in-flight download. Signatures are verified once the file is downloaded, then the file hash is checked before saving. Full signers chain validation is always performed; there is no option to skip it.

If the file has been revoked, a warning is printed to stderr and the download is aborted.

Arguments

`<FILE_URL>`

Public URL of the file to download. For example:

https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

Options

`-o --output <PATH>`

Output file path. Defaults to the filename extracted from the URL.

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--type <FORGE_TYPE>`

Override automatic forge type detection.

Value	Description
`github`	GitHub release
`gitlab`	GitLab release
`fileserver`	Generic file server

Environment

ASFALOAD_BACKEND_URL — alternative to --backend-url (an explicit --backend-url wins).

Output

The command prints progress to stdout as each step completes:

Starting download: https://github.com/acme/tool/releases/download/v1.0/tool.tar.gz
✓ Downloaded index file (567 bytes)
✓ Downloaded signatures file (890 bytes)
Downloading tool.tar.gz
Progress: 2.00 MB
✓ Signers chain history verified (3 entries)
✓ Signatures verified successfully (2 valid)
✓ Download complete (12.50 MB)
✓ File hash verified (SHA-256)
✓ File saved to: ./tool.tar.gz
✓ All done! Verified 2 signature(s)

Notes:

The file download, signers chain validation, and revocation probe run in parallel, so Progress: and ✓ Signers chain history verified lines may interleave in any order.
Progress lines are emitted at milestones (roughly every megabyte), overwriting each other with \r; the shown Progress: 2.00 MB is one such milestone.
If any signature is invalid, a ⚠ Warning: N invalid signature(s) line precedes the ✓ Signatures verified successfully line.
A ✗ Signers chain verification failed: <reason> line goes to stderr when chain validation fails.

If the file has been revoked:

This file has been revoked.
  Revoked at: 2025-03-15T10:30:00Z
  Revoked by: asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

Examples

# download and verify a release artifact
asfaload-cli download \
    https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

# save to a specific path
asfaload-cli download -o /tmp/tool.tar.gz \
    https://github.com/acme/tool/releases/download/v1.0/tool-linux-amd64.tar.gz

# override forge detection
asfaload-cli download --type gitlab \
    https://gitlab.com/acme/tool/-/releases/v1.0/downloads/tool.tar.gz

Exit codes

0 — download and verification succeeded.
non-zero — error (verification failure, revoked file, network error).

`asfaload-cli ping`

Usage: asfaload-cli ping [OPTIONS]
Source: src/commands/ping.rs

Check that the backend is reachable. Without a secret key the request is unauthenticated and simply confirms connectivity. With a secret key the request is authenticated, and the backend reports whether your credentials were accepted and for which public key — useful for diagnosing key or clock problems before running a command that signs.

Options

`-K --secret-key <PATH>`

Path to your secret key file (asfaload or OpenSSH ed25519). Optional — when given, the ping is authenticated, and a password is required to use the key.

`-p --password <PASSWORD>`

Password for the secret key. Only used when --secret-key is given. Conflicts with --password-file and --password-command. Prompted interactively if none of these is set.

`-P --password-file <PATH>`

File containing the password. Conflicts with --password and --password-command.

`-c --password-command <COMMAND>`

`-u --backend-url <URL>`

Backend API URL. Defaults to https://backend.asfaload.com.

`--json`

Emit the backend response as JSON instead of human-readable text.

Environment

ASFALOAD_SECRET_KEY — alternative to --secret-key.
ASFALOAD_BACKEND_URL — alternative to --backend-url.
ASFALOAD_PASSWORD_FILE — alternative to --password-file.
ASFALOAD_PASSWORD_COMMAND — alternative to --password-command.
ASFALOAD_PING_PASSWORD — alternative to --password (still supported, lower precedence).
ASFALOAD_PING_PASSWORD_FILE — alternative to --password-file (still supported, lower precedence).

Output

Human-readable (default), unauthenticated:

pong from https://backend.asfaload.com — unauthenticated

Authenticated successfully:

pong from https://backend.asfaload.com — authenticated as asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8

Authentication attempted but failed:

pong from https://backend.asfaload.com — auth FAILED for key asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8: Replay attack detected: nonce already used

JSON (with --json):

{"message":"pong","auth":{"status":"unauthenticated"}}
{"message":"pong","auth":{"status":"success","public_key":"asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8"}}
{"message":"pong","auth":{"status":"failed","public_key":"asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8","reason":"Replay attack detected: nonce already used"}}

Examples

# check connectivity (unauthenticated)
asfaload-cli ping

# verify your credentials are accepted
asfaload-cli ping -K ~/.asfaload/mykey

# against a non-default backend
asfaload-cli ping -u https://my-asfaload-deployment.example.com

Exit codes

0 — backend reachable; either an unauthenticated ping or authentication succeeded.
non-zero — backend unreachable, or authentication was attempted and failed.

rest-api manual

Reference for the Asfaload REST API.

Authentication

Authenticated endpoints require four HTTP headers, signing the request with the caller’s Ed25519 secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format (e.g. 2025-06-17T14:03:22.123456789+00:00). It must be in canonical UTC form: offset written as +00:00 (never Z or another offset), and fractional seconds with no trailing zeros (omitted entirely when zero). This is exactly what chrono’s DateTime::<Utc>::to_rfc3339() emits. The server normalizes any valid RFC 3339 timestamp to this form before verifying the signature, so a validly-signed request with a non-canonical timestamp string is rejected.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — base64-encoded (unpadded) Ed25519 signature, computed as described below.
X-asfld-pk — caller’s public key in asfaload format: the literal prefix asfaload-pub: followed by the base64 encoding (standard alphabet, unpadded) of the 32 raw key bytes (e.g. asfaload-pub:b5S+CxuqICIUn/DGBdMKeTMZCgQcg78ohiWQ1sC00c8).

Computing the signature

Build the canonical request string by joining the timestamp, the nonce and the request payload with the ## separator:
```
{timestamp}##{nonce}##{payload}
```
- timestamp — the exact string sent in X-asfld-timestamp, which must already be in the canonical form described above.
- nonce — the exact string sent in X-asfld-nonce.
- payload — the raw request body as a UTF-8 string. For requests without a body (e.g. GET /v1/ping), use the empty string.
Compute the SHA-512 digest of the canonical request string. The digest is used raw (64 bytes); do not hex- or base64-encode it.
Sign the raw digest bytes with the Ed25519 secret key: the signature covers the digest itself, not the canonical string.
Base64-encode (unpadded) the 64-byte signature and send it in X-asfld-sig.

Pseudocode:

canonical = timestamp + "##" + nonce + "##" + payload
digest    = SHA-512(canonical)                        // 64 raw bytes
signature = Ed25519-sign(secret key, digest)
sig header = base64(signature)                        // unpadded
pk header  = "asfaload-pub:" + base64(public key)     // unpadded, 32 raw bytes

The server rebuilds the canonical request string from the received headers and body, computes its SHA-512 digest, and verifies the signature with the transmitted public key. A request is rejected when its timestamp’s age — truncated to whole minutes — exceeds 5 minutes (so requests up to just under 6 minutes old are accepted), when it is more than 10 seconds in the future, when the nonce was already used, or when the signature does not verify.

Registration

POST /v1/register_repo — register a new project with the signing server
POST /v1/update_signers — propose an update to a project’s signers file

Signatures

POST /v1/signatures — submit signatures for a file
GET /v1/signatures/{file_path} — query signature collection status for a file
GET /v1/pending_signatures — list files awaiting the caller’s signature

Files

GET /v1/files/{file_path} — fetch raw file content from the repository
GET /v1/files-to-sign/{file_path} — fetch file contents needed for signing

Signers

GET /v1/get_signers/{file_path} — get the signers configuration for a path
GET /v1/get_signers_chain/{artifact_path} — get the signers history chain for a signed artifact

Revocation

POST /v1/revoke — revoke a previously signed file

Assets

POST /v1/assets — register assets from a GitHub release or checksums files

`POST /v1/register_repo`

Auth: required
Source: src/handlers.rs — register_repo_handler

Register a new project with the signing server. The server fetches the signers file from the forge URL, validates it, creates the directory structure, records the first signature, and commits the result to the backing Git repository.

A project can only be registered once. Calling this endpoint again for an already-registered project returns an error.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Request body

JSON object:

{
  "signers_file_url": "https://github.com/acme/repo/blob/main/asfaload.signers.json",
  "public_key": "<base64-public-key>"
}

Fields:

signers_file_url — URL pointing to the signers file on the forge (GitHub, GitLab, or file server).
public_key — base64-encoded Ed25519 public key of the submitter. Must match one of the keys in the signers file.

Response

`200 OK`

{
  "success": true,
  "project_id": "https/github.com/443/acme/repo",
  "message": "Project registered successfully. Collect signatures to activate.",
  "required_signers": ["<base64-public-key-1>", "<base64-public-key-2>"],
  "signature_submission_url": "/v1/signatures"
}

Fields:

success — always true on success.
project_id — normalised identifier for the registered project.
message — human-readable status message.
required_signers — list of base64-encoded public keys that still need to sign.
signature_submission_url — path to use for submitting signatures.

Errors

400 Bad Request — invalid or unparseable forge URL, or invalid public key.
401 Unauthorized — missing or invalid authentication headers.
409 Conflict — project is already registered or registration is in progress.
500 Internal Server Error — forge validation, signers initialisation, or Git commit failed.

Examples

Successful registration

curl -sS -X POST 'http://127.0.0.1:3000/v1/register_repo' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "signers_file_url": "https://github.com/acme/repo/blob/main/asfaload.signers.json",
    "public_key": "<base64-public-key>"
  }'

{"success":true,"project_id":"https/github.com/443/acme/repo","message":"Project registered successfully. Collect signatures to activate.","required_signers":["<base64-pk-1>","<base64-pk-2>"],"signature_submission_url":"/v1/signatures"}

Project already registered

HTTP/1.1 409 Conflict

{"error":"Project 'https/github.com/443/acme/repo' is already registered or registration is in progress."}

`POST /v1/update_signers`

Auth: required
Source: src/handlers.rs — update_signers_handler

Propose an update to a project’s signers file. The server fetches the new signers file from the forge, validates it, writes it as a pending proposal, and commits the result. The project must already be registered and have an active signers file.

Like initial registration, the update requires all new signers to submit their signatures before it takes effect.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Request body

JSON object (same shape as register_repo):

{
  "signers_file_url": "https://github.com/acme/repo/blob/main/asfaload.signers.json",
  "public_key": "<base64-public-key>"
}

Fields:

signers_file_url — URL pointing to the updated signers file on the forge.
public_key — base64-encoded Ed25519 public key of the submitter.

Response

`200 OK`

{
  "success": true,
  "project_id": "https/github.com/443/acme/repo",
  "message": "Signers update proposed successfully. Collect signatures to activate.",
  "required_signers": ["<base64-public-key-1>", "<base64-public-key-2>"],
  "signature_submission_url": "/v1/signatures"
}

Fields:

success — always true on success.
project_id — normalised project identifier.
message — human-readable status message.
required_signers — list of base64-encoded public keys that need to sign the update.
signature_submission_url — path to use for submitting signatures.

Errors

400 Bad Request — project not registered, no active signers file, invalid forge URL, or invalid public key.
401 Unauthorized — missing or invalid authentication headers.
500 Internal Server Error — forge validation, proposal creation, or Git commit failed.

Examples

Successful update proposal

curl -sS -X POST 'http://127.0.0.1:3000/v1/update_signers' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "signers_file_url": "https://github.com/acme/repo/blob/main/asfaload.signers.json",
    "public_key": "<base64-public-key>"
  }'

{"success":true,"project_id":"https/github.com/443/acme/repo","message":"Signers update proposed successfully. Collect signatures to activate.","required_signers":["<base64-pk-1>","<base64-pk-2>"],"signature_submission_url":"/v1/signatures"}

Project not registered

HTTP/1.1 400 Bad Request

{"error":"Project 'https/github.com/443/acme/repo' is not registered. Register the repo first."}

`POST /v1/signatures`

Auth: required
Source: src/handlers.rs — submit_signature_handler

Submit one or more signatures for a file. The server validates each signature against the signer’s public key and the file content, adds it to the pending collection, and commits the result to Git. Once all required signatures are collected, the aggregate signature is marked complete.

For signers files, the request must include signatures for both the signers file itself and its metadata file.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Request body

JSON object:

{
  "file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
  "public_key": "<base64-public-key>",
  "signatures": {
    "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json": "<base64-signature>"
  }
}

Fields:

file_path — mirror-relative path to the primary file being signed.
public_key — base64-encoded Ed25519 public key of the signer.
signatures — map of file paths to their base64-encoded Ed25519 signatures. Must include at least the primary file_path. For signers files, include the metadata file path as well.

Response

`200 OK`

{
  "is_complete": false
}

Fields:

is_complete — true when all required signatures have been collected; false while signatures are still pending.

Errors

400 Bad Request — empty file path, file not found, invalid public key or signature format, or no signature provided for the primary file.
401 Unauthorized — missing or invalid authentication headers.
409 Conflict — signature already collected for this key, or signature already added.
500 Internal Server Error — signature collection or Git commit failed.

Examples

Successful submission (collection not yet complete)

curl -sS -X POST 'http://127.0.0.1:3000/v1/signatures' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
    "public_key": "<base64-public-key>",
    "signatures": {
      "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json": "<base64-signature>"
    }
  }'

{"is_complete":false}

File not found

HTTP/1.1 400 Bad Request

{"error":"File not found: https/github.com/443/acme/repo/releases/tag/v1.0/missing.json"}

`GET /v1/signatures/{file_path}`

Auth: required
Source: src/handlers.rs — get_signature_status_handler
Related command: client signature-status

Return the current signature collection status of a file. Authorization is checked against the current global signers file, not the copy frozen at the file’s registration time; this keeps revocation semantics uniform across all authenticated endpoints.

Path parameters

`file_path`

Mirror-relative path to the file. Slashes are preserved (the route uses a catch-all parameter).

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Response

`200 OK`

{
  "file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
  "is_complete": false
}

Fields:

file_path — normalized mirror-relative path to the file.
is_complete — true once the aggregate signature threshold has been met; false while signatures are still being collected.

Errors

400 Bad Request — path is empty.
401 Unauthorized — missing or invalid authentication headers.
403 Forbidden — caller’s public key is not in the file’s current signers file.
404 Not Found — no file exists at the given path, or no signers file could be located for it.
500 Internal Server Error — backend failure (read, parse, or actor error).

Examples

Successful query

curl -sS 'http://127.0.0.1:3000/v1/signatures/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>'

{"file_path":"https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json","is_complete":false}

Caller not an authorized signer

curl -sS -i 'http://127.0.0.1:3000/v1/signatures/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-non-signer-public-key>'

HTTP/1.1 403 Forbidden

`GET /v1/pending_signatures`

Auth: required
Source: src/handlers.rs — get_pending_signatures_handler

List all files that still need the caller’s signature. The server walks the repository, finds files with pending aggregate signatures, and filters to those where the caller is an authorized signer who has not yet signed.

The returned paths point to the artifact files themselves, not to the .signatures.json.pending files used internally.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Response

`200 OK`

{
  "file_paths": [
    "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
    "https/github.com/443/acme/repo/asfaload.signers.pending/asfaload.signers.json"
  ]
}

Fields:

file_paths — list of mirror-relative paths to files awaiting the caller’s signature. Empty array if nothing is pending.

Errors

401 Unauthorized — missing or invalid authentication headers.
500 Internal Server Error — failed to scan repository or check signer authorization.

Examples

Files pending signature

curl -sS 'http://127.0.0.1:3000/v1/pending_signatures' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>'

{"file_paths":["https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json"]}

Nothing pending

{"file_paths":[]}

`GET /v1/files/{file_path}`

Auth: none
Source: src/handlers.rs — get_file_handler

Fetch the raw content of a file from the repository. Returns the file as an application/octet-stream byte stream. This is a public endpoint — no authentication is required.

The server validates the path against directory traversal attempts before reading.

Path parameters

`file_path`

Mirror-relative path to the file. Slashes are preserved (the route uses a catch-all parameter).

Response

`200 OK`

Raw file bytes with headers:

Content-Type: application/octet-stream
Content-Length: <size-in-bytes>

Errors

400 Bad Request — invalid file path or path traversal detected, or path points to a directory.
404 Not Found — file does not exist.
500 Internal Server Error — failed to read the file.

Examples

Fetch a file

curl -sS 'http://127.0.0.1:3000/v1/files/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json' \
  -o index.json

File not found

curl -sS -i 'http://127.0.0.1:3000/v1/files/https/github.com/443/acme/repo/releases/tag/v1.0/missing.json'

HTTP/1.1 404 Not Found

{"error":"File not found: https/github.com/443/acme/repo/releases/tag/v1.0/missing.json"}

`GET /v1/files-to-sign/{file_path}`

Auth: required
Source: src/handlers.rs — get_files_to_sign_handler

Fetch the contents of all files that need to be signed for a given artifact. For regular files, the response contains only the primary file. For signers files, it includes both the signers file and its metadata file. All contents are base64-encoded.

This endpoint is used by the client CLI during the sign-pending workflow to retrieve file contents before computing signatures locally.

Path parameters

`file_path`

Mirror-relative path to the file. Slashes are preserved (the route uses a catch-all parameter).

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Response

`200 OK`

For a regular artifact:

{
  "files": {
    "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json": "<base64-content>"
  }
}

For a signers file (includes metadata):

{
  "files": {
    "https/github.com/443/acme/repo/asfaload.signers.pending/asfaload.signers.json": "<base64-content>",
    "https/github.com/443/acme/repo/asfaload.signers.pending/asfaload.signers.json.metadata.json": "<base64-content>"
  }
}

Fields:

files — map of mirror-relative file paths to their base64-encoded contents.

Errors

400 Bad Request — invalid file path.
401 Unauthorized — missing or invalid authentication headers.
404 Not Found — file does not exist.
500 Internal Server Error — failed to determine file type, read file, or locate metadata file for a signers file.

Examples

Fetch files for a release artifact

curl -sS 'http://127.0.0.1:3000/v1/files-to-sign/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>'

{"files":{"https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json":"<base64-content>"}}

File not found

HTTP/1.1 404 Not Found

{"error":"File not found: https/github.com/443/acme/repo/releases/tag/v1.0/missing.json"}

`GET /v1/get_signers/{file_path}`

Auth: none
Source: src/handlers.rs — get_signers_handler

Fetch the signers configuration that applies to a given path. The server walks parent directories from the given path upward until it finds an active signers file, then returns its raw JSON content. This is a public endpoint — no authentication is required.

Path parameters

`file_path`

Mirror-relative path to any file or directory in the repository. The server locates the nearest signers file by traversing parent directories. Slashes are preserved (the route uses a catch-all parameter).

Response

`200 OK`

Raw signers file JSON with headers:

Content-Type: application/json
Content-Length: <size-in-bytes>

The body is the signers configuration file as stored on disk — a SignersConfig JSON object.

Errors

400 Bad Request — invalid file path.
404 Not Found — no signers file found in any parent directory of the given path.
500 Internal Server Error — failed to read the signers file.

Examples

Fetch signers for a release artifact

curl -sS 'http://127.0.0.1:3000/v1/get_signers/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json'

Returns the content of the nearest asfaload.signers/asfaload.signers.json ancestor.

No signers file found

curl -sS -i 'http://127.0.0.1:3000/v1/get_signers/https/github.com/443/unknown/repo/file.txt'

HTTP/1.1 404 Not Found

{"error":"No signers file found for: https/github.com/443/unknown/repo/file.txt. Error: No signers file found in parent directories"}

`GET /v1/get_signers_chain/{artifact_path}`

Auth: none
Source: src/handlers.rs — get_signers_chain_handler

Fetch the signers history chain for a signed artifact. The server traces the artifact’s local signers copy back to its source commit, reads the history file and all associated signers/metadata/signature files at that point in time, and returns the chain of signers configurations that were active up to and including the one used to sign the artifact.

This endpoint is useful for verifying the full provenance of an artifact’s signing authority.

Path parameters

`artifact_path`

Mirror-relative path to the signed artifact. Slashes are preserved (the route uses a catch-all parameter).

Response

`200 OK`

{
  "history": {
    "entries": [
      {
        "signers_config": "...",
        "signatures": "...",
        "metadata": "...",
        "metadata_signatures": "...",
        "timestamp": "2024-04-11T12:00:00Z"
      }
    ]
  }
}

Fields:

history — a HistoryFile object containing the chain of signers configurations. Each entry includes the signers config, its signatures, metadata, metadata signatures, and the timestamp when it became active. The chain is filtered to entries relevant to the artifact’s signing time.

Errors

400 Bad Request — invalid artifact path or cannot derive signers path.
500 Internal Server Error — failed to trace signers source, read files from Git history, or build the chain.

Examples

Fetch the signers chain

curl -sS 'http://127.0.0.1:3000/v1/get_signers_chain/https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json'

{"history":{"entries":[...]}}

Invalid artifact path

curl -sS -i 'http://127.0.0.1:3000/v1/get_signers_chain/invalid'

HTTP/1.1 400 Bad Request

{"error":"Invalid artifact path: ..."}

`POST /v1/revoke`

Auth: required
Source: src/handlers.rs — revoke_handler

Revoke a previously signed file. The caller provides a revocation document (as a JSON string), a signature over its SHA-512 digest, and their public key. The server validates that the file has a complete aggregate signature, verifies the revocation authorization, and records the revocation.

Only files with a complete aggregate signature can be revoked. Files that are still collecting signatures or already revoked are rejected.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Request body

JSON object:

{
  "file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
  "revocation_json": "{\"reason\":\"compromised\",\"timestamp\":1712860800}",
  "signature": "<base64-signature>",
  "public_key": "<base64-public-key>"
}

Fields:

file_path — mirror-relative path to the signed file being revoked.
revocation_json — JSON string of the revocation document (RevocationInfo).
signature — base64-encoded Ed25519 signature of the SHA-512 digest of revocation_json.
public_key — base64-encoded Ed25519 public key of the revoker.

Response

`200 OK`

{
  "success": true,
  "message": "File revoked successfully"
}

Fields:

success — always true on success.
message — human-readable confirmation.

Errors

400 Bad Request — empty file path, invalid public key or signature format, digest mismatch, file already revoked, or revocation authorization failed.
401 Unauthorized — missing or invalid authentication headers.
404 Not Found — file does not exist.
409 Conflict — file has not been fully signed yet.
500 Internal Server Error — revocation processing or Git commit failed.

Examples

Successful revocation

curl -sS -X POST 'http://127.0.0.1:3000/v1/revoke' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json",
    "revocation_json": "{\"reason\":\"compromised\",\"timestamp\":1712860800}",
    "signature": "<base64-revocation-signature>",
    "public_key": "<base64-public-key>"
  }'

{"success":true,"message":"File revoked successfully"}

File not fully signed

HTTP/1.1 409 Conflict

{"error":"File has not been fully signed: https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json"}

`POST /v1/assets`

Auth: required
Source: src/handlers.rs — register_assets_handler

Register assets for signing. Accepts either a GitHub release URL or a list of checksums file URLs — exactly one must be provided.

In GitHub mode, the server fetches the release metadata, downloads all assets, builds an index file, and commits everything to the repository. In checksums mode, it downloads the referenced checksums files, builds the index, and commits.

Request headers

Standard Asfaload authentication headers, signed by the caller’s secret key:

X-asfld-timestamp — request timestamp, RFC 3339 format.
X-asfld-nonce — random UUID v4, unique per request.
X-asfld-sig — Ed25519 signature, computed as described in Authentication.
X-asfld-pk — caller’s public key.

Request body

JSON object with exactly one of the two fields set:

GitHub release mode

{
  "github_release_url": "https://github.com/acme/repo/releases/tag/v1.0"
}

Checksums mode

{
  "csum_files": [
    "https://example.com/releases/v1.0/SHA256SUMS",
    "https://example.com/releases/v1.0/SHA512SUMS"
  ]
}

Fields:

github_release_url — full URL to a GitHub release page. Must point to a known GitHub host. Mutually exclusive with csum_files.
csum_files — list of URLs to checksums files. All URLs must share the same origin and parent directory. Mutually exclusive with github_release_url.

Response

`200 OK`

{
  "success": true,
  "message": "Release registered successfully",
  "index_file_path": "https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json"
}

Fields:

success — always true on success.
message — human-readable status. Either “Release registered successfully” (GitHub mode) or “Assets registered successfully” (checksums mode).
index_file_path — mirror-relative path to the generated index file.

Errors

400 Bad Request — both or neither fields provided, invalid URL format, non-GitHub host for github_release_url, or invalid checksums URLs.
401 Unauthorized — missing or invalid authentication headers.
409 Conflict — release already registered.
500 Internal Server Error — release processing, checksums download, or Git commit failed.

Examples

Register a GitHub release

curl -sS -X POST 'http://127.0.0.1:3000/v1/assets' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "github_release_url": "https://github.com/acme/repo/releases/tag/v1.0"
  }'

{"success":true,"message":"Release registered successfully","index_file_path":"https/github.com/443/acme/repo/releases/tag/v1.0/asfaload.index.json"}

Register checksums files

curl -sS -X POST 'http://127.0.0.1:3000/v1/assets' \
  -H 'Content-Type: application/json' \
  -H 'X-asfld-timestamp: 2024-04-11T20:00:00+00:00' \
  -H 'X-asfld-nonce: <random-uuid-v4>' \
  -H 'X-asfld-sig: <base64-signature>' \
  -H 'X-asfld-pk: <base64-public-key>' \
  -d '{
    "csum_files": ["https://example.com/releases/v1.0/SHA256SUMS"]
  }'

{"success":true,"message":"Assets registered successfully","index_file_path":"https/example.com/443/releases/v1.0/asfaload.index.json"}

Mutually exclusive fields

HTTP/1.1 400 Bad Request

{"error":"github_release_url and csum_files are mutually exclusive"}

Keyboard shortcuts

Asfaload Documentation
